Applications

• Application: Ultracleaning of air and gases, Particle Removal
• Application Area: Analytical Sample Preparation

Compliance Information

• Extractables: HPLC certified

Connections (Physical)

• Connector Inlet: Female Luer Lock
• Connector Outlet: Male Luer Slip

Dimensions

• Filter Diameter: ⌀ 25 mm
• Filtration Area: 4.8 cm²

General Specifications

• Filter Paper / Membrane Color: White (opaque), Printed
• Flow Rate: ≥ 260 mL/min for methanol at 1 bar (14.5 psi) | ≥ 3000 mL/min for air at 0.1 bar (1.5 psi)
• Total Throughput: Up to 100 mL
• pH Range: 1.0 – 14.0

Materials of Construction

• Housing Material: Polypropylene (PP)
• Membrane Material: Polytetrafluorethylene (PTFE)

Operating Conditions

• Maximum Operating Temperature: 60 °C (140 °F)
• Operating Pressure: 4.5 bar (65 psi)
• Maximum Operating Pressure: 4.5 bar (65 psi)

Physicochemical Information

• Pore Size: 0.45 µm
• Bubble Point: ≥ 0.9 bar (13 psi) with ethanol
• Burst Pressure: ≥ 7.0 bar (102 psi)
• Wettability: Hydrophobic

Product Information

• Brand: Minisart® SRP
• Device Type: Syringe Filters
• Pack Size: 50
• Packaging: Bulk packed
• Sample Type: Solvents, Air/Gas, Acids, Bases

Sterility / Purity

• Delivery Condition: Non-Sterile
• Sterilization Method: Ethylene oxide, Autoclave

Volume

• Hold-up Volume: ≤ 100 – 200 µL
